Individual UAV Detection and Early Warning Instrument

GWDEF-RM100

The device adopts self-developed low-power digital-analog hybrid receiver technology and advanced power management technology, featuring an external ultra-wide band antenna, capable of accurately detecting common civilian drones including quadcopters, fixed-wing drones, DIY drones, and racing drones, achieving precise audio, visual, and vibration alerts while maintaining an extremely low false alarm rate in complex electromagnetic environments. It boasts high sensitivity and low false alarm rates, is compact in size, and shielding well.

Equipment features:

1. 2.4/5.8 dual frequency receiving antenna: The antenna uses SMA interface, alarm output on LCD display; it can work normally in low temperature environment, the interface displays various working status of the equipment.

2. Functional operation keyboard: switching device lock and other functions in three languages (Chinese, English and Russian).

3. Switch and alarm volume adjustment: the turning button can control the on and off while at the same time adjust the alarming volume

Equipment Application:

It is used to cooperate with portable UAV interference equipment to compensate for the problem of untimely detection of UAVs in work; it is used for police personnel and vehicles to patrol on the move, so as to detect UAVs around them in the first time.

Technical Parameter:



Index	Technical Parameters and Requirements
Detection band	2400~2485MHz  5150~5950MHz
Identification type	DJI full series Daotong full series mainstream WiFi 5.8GHz image transmission racing drones (FPV)
Battery Capacity	29.6Wh(7.4V）
Battery life	8 hours (dual power)
Appearance dimension	135×62×38mm (including antenna)
Working weight	270g
Detection radius	2000m (depending on the electromagnetic strength of the environment)
Protection level	IP67
